MINI HEATING UP” FUNCTION
The mini heating up function is for PRANA 160, PRANA 210G and PRANA 210C models. It allows you to ex-tend the temperature range of the Prana system to -25 ° C (-30 ° C). The function is turned on or/ off using the remote control or via the app.
In extreme temperatures, winter mode will prevent the heat exchanger and fans of the recuperator from freezing. In night mode, the temperature of the inflow air is increased by an additional 3–-4 ° C.
“WINTER MODE”
The function in the WINTER MODE is intended to prevent icing of condensate drain during cold season or to freeze it if icing has occured.
To avoid icing and to ensure the correct operation of the recuperator at a minus temperature outside, the use of the “Winter Mode” is obligatory.
The diameter of the mounting hole: 162 mm
The length of the working module: from 350 mm
The recommended area of the premises: up to 60 m2.
The volume of air exchange during recuperation:
Supply: 105 m3 / h
Exhaust: 97 m3 / h
In the “night mode”: 12 m3 / h
Heat recovery efficiency: 95%
Electricity consumption: from 3,6 W* h to 17 W * h
Control system: remote control or the Android mobile application.
The “Mini after-heating” function*
The function in the “Winter mode” **
The function in the “Auto-mode” ***
Due to the irregular shaped channels of the copper heat exchanger, the noise level is reduced by 7-8 times compared to the initial level.
Separate control of the inflow and exhaust.
